B2UMPBOA-3 X 2½-316L-PL

B2UMPBOA-3 X 2½-316L-PL - BPE USE POINT 20RA SF1
Manufacturer:Alfa Laval
Product code: 5016
Item number: 9634037420
In stock:
The green marker indicates that the product is typically in stock.. The yellow marker indicates that the product typically has a little longer lead time
HS Code: 7307290090
Delivery time:On request
  • Range: Bends
  • Product model: Tri-Clover BPE Use-Point
  • Size: 3"
  • Second size: 2.5"
  • Material: 316L
  • Finish: SF1(PL) (ID=20/OD=32µin)
  • Connection type: Weld and Tri-Clamp and Weld
  • Standard: UltraPure
  • Design: B2UMPBOA
  • Item Weight: 1.81
  • Country of origin:
Price:
Login to view price

Tax excluded

A: 165.10
B: 228.60
C: 219.10
OD/ID x t: 76.20/72.90 x 1.65
OD1/ID1 x t1: 76.20/72.90 x 1.65
OD2/ID2 x t2: 63.50/60.20 x 1.65
