INSPECTION PORT O-440X320-IO

INSPECTION PORT O-440X320-IO - 080-Q-4404-SS HANDLE-LID 2.0 FRAME8-EXT.HINGE
Manufacturer:Alfa Laval
Product code: 5517
Item number: 9614450847
In stock:
The green marker indicates that the product is typically in stock.. The yellow marker indicates that the product typically has a little longer lead time
HS Code: 84229090
Delivery time:On request
  • Range: Oval covers
  • Size mm: 440x320
  • Material: 1.4404 (316L)
  • Inside surface quality: Electropolished on Lid to Ra≤0.8 µm and Acid pickled on Frame to Ra≤3.0 µm
  • Position on tank: Below liquid level - on side of the tank
  • Handle design: Handwheel
  • Hinge direction: Neutral
  • Pressure bar: Static
  • Frame height: 80
  • Item weight: 8.7 kg
Price:
Login to view price

Tax excluded
